"The Difference is in the Details."
We realize that many companies make this claim, however, Superior Tooling's
engineering and design department uses the latest powerful solid modeling and
machining software to develop new innovative products.
About Us
Superior Tooling, owned by Terry, Jim and Leo Williams,
is recognized for the exceptional quality, craftsmanship and precision in
custom machining and design.
Tooling
We build our own special jigs and machine tools as
required. We have extensive resources for developing processes that produce
unsurpassed parts. The phrase "We can't manufacture that," is not acceptable.
We continually strive for perfection.
Quality Control
Superior's Quality Plan conforms to all points of ISO
9001:2000, MIL-I-45208, and MIL-Q-9858A. Seeking constant improvement is a
hallmark of Superior Tooling's machinists and engineers. This philosophy is
demonstrated throughout our entire business. We machine and manufacture
on-site and are committed to producing precise, quality parts. Our
technologically advanced engineering department allows us to design and
prototype specific products based upon customer specifications.
Typical Work
-
Progressive & single stage stamping dies
-
Draw forming
-
Rotary draw & press bend tube bending tooling
-
Tube coping & cutoff dies
-
Special cutting tools
-
Broaches
-
Machined components
-
Special machines as well as repair, rebuild, and reconfiguration
-
Contract design
-
Weld fixtures design & build
-
Reverse engineering
-
Government contracting
-
Department of Defense lebeling service
-
Contract inspection
-
Stamping & forming die components
-
Component repair & welding
-
Fabrication
-
Contract CNC programming
Capabilities
Superior Tooling is equipped with enough machining power to efficiently
accommodate both large and small project sizes.. Armed with an impressive
lineup of equipment, we can turn out a wide variety of custom products. With an
operating space of almost 20,000 sq. ft., Superior is your single resource for
custom machining.
Production
Superior utilizes multiple high speed computerized numerical control (CNC)
machining centers, turning centers and precision grinding machines. In almost
all operations, high precision ruby tipped measuring probes ensure uniformity
and real time measurements.
Engineering
State of the art computer aided drafting (CAD) and design, utilizing
Solidworks, AutoCAD and Gibbs. Three dimensional modeling and file importation
from our customers is the norm.
Quality
We take quality assurance seriously with constant improvement and
demonstrated repeatability. In house heat treating, hardness testing and a wide
variety of inspection equipment complete our quality philosophy.
Equipment
- Solidworks 2010
- GIbbscam 2010
- Espirit 2003
- Automation Direct PLC Programming
- Qty. = 1 Cincinnati Milacron Arrow 750 VMC, 30X x 20Y x 20 Z
- Qty. = 2 Cincinnati Milacron Sabre 1250 VMC, 50X x 30Y x 30Z
- Qty. = 1 Cincinnati Milacron Sabre 1500 VMC, 60X x 30Y x 30Z
- Qty. = 1 Mazak H-400 HMC, 16X x 16Y x 21Z, twin pallet
- Qty. = 6 Toyoda N-Topcenter HMC, 20X x 16Y x 16Z, twin pallet, full contouring 4th axis
- Qty. = 1 Cincinnati Milacron 12U x 60 MO Series, Fanuc
0-TD
- Qty. = 1 Citizen Cincom F-10 swiss turning center,
twin turret with barfeed
- Qty. = KSI Swiss SQC32 32MM 7 axis turning center, 4
live crossworking, 4 live endworking, 6 turning, 8 stationary endworking -
modified for 38MM capacity in main spindle, 32MM in subspindle, Automatic
Hydrobar barfeed
- Qty. = 1 Mitsubishi DWC-110H - 11X x 17Y x 10 thick 4 axis wire edm - manufactured 1986
- Qty. = 1 Mitsubishi DWC-110HA - 11X x 17Y x 10 thick 4 axis wire EDM - manufactured 1989
- Qty. = 1 Elox Model B CNC sinker EDM, Fanuc11
- Qty. = 2 Kearney Trecker #3H Universal Horizontal Mill
- Qty. = 1 Kearney Trecker #2H Universal Horizontal Mill
- Qty. = 2 Greaves #2 Plain Horizontal Mill
- Qty. = 1 Kearney Trecker #3 Plain Vertical Mill
- Qty. = 1 Kearney Trecker #K Vertical Mill
- Qty. = 1 Kearney Trecker #4H Vertical Mill
- Qty. = 1 1 Cincinnati #4 Horizontal Mill
- Qty. = 1 Bridgeport Series 2 Standard vertical mill with DRO
- Qty. = 2 Bridgeport Series 1 with DRO
- Qty. = 2 US Burke Rise and fall Horizontal Production Mill
- Qty. = 1 Cincinnati Gilbert 3-1/2 T Horizontal Boring Mill, 72X x 72Y x 48Z x 24" quill travel
- Qty. = 1 Monarch EE 10 x 20 toolroom lathe, 1959
- Qty. = 1 Monarch EE 10 x 20 Manufacturing turret lathe, 1959
- Qty. = 1 Clausing Colchester Series 8000 17 x 80, 1976
- Qty. = 1 Monarch EC turret lathe, 6 x 10, 1969
- Qty. = 1 Monarch EE 10 x 20 Toolroom lathe, 1952
- Qty. = 2 Monarch EE 10 x 20 toolroom lathe, 1943
- Qty. = 1 Moore #2 Jig grinder, 40,000 and 100,000 rpm heads
- Qty. = 1 Thompson broach grinder
- Qty. = 1 Taft Pierce #1 5 x 12 surface grinder
- Qty. = 2 Gallmeyer and Livingston 12 x 24 Surface grinder
- Qty. = 1 Gallmeyer and Linvingston 12 x 36 Surface Grinder
- Qty. = 1 Winslowmatic drill sharpener
- Qty. = 1 Pratt Whitney R8 tool and cutter grinder
- Qty. = 1 Cincinnati #2 tool and cutter grinder
- Qty. = 1 Brierly ZB-80 Tool and cutter grinder
- Qty. = 1 Norton Model CTU 12 x 48 O.D. Grinder
- Qty. = 1 Landis 10 x 20 Model C OD grinder
- Qty. = 1 Norton 10 x 24 Universal OD/ID grinder
- Qty. = 1 Darex M5 Drill sharpener
- Qty. = 1 Rockford Hydraulic 16 inch horizontal shaper
- Qty. = 1 Smith and Mills 16 inch mechanical horizontal shaper
- Qty. = 1 Pratt Whitney model B 6 inch vertical shaper
- Qty. = 1 Superior built 5 ton x 36" pull vertical broach
- Qty. = 1 Oilgear 25 ton x 90" pull Horizontal Broach
- Qty. = 1 Beyer Pressure bore twin spindle gundrilling machine, 1.25 capacity x 11 inch stroke
- Qty. = 2 Leland Gifford 2LMS 4 spindle gang drill
- Qty. = 1 Leland Gifford 2LMS 3 spindle gang drill
- Qty. = 1 Leland Gifford 2LMS 2 spindle gang drill
- Qty. = 1 Leland Gifford 2LMS single spindle drill
- Qty. = 1 Fosdick Hydraulic 4 foot arm radial drill
- Qty. = 1 Cincinnati Bickford 4 spindle gang drill
- Qty. = 1 Chas Allen 4 spindle gang drill
- Qty. = 1 Wilton single spindle geared head drill press
- Qty. = 1 Clausing single spindle drill press
- Qty. = 1 Burgmaster 6 position turret drill
- Qty. = 1 Superior built micro hole gundrill
- Qty. = 1 Sheffield Discovery D-8 DCC cmm with motorized probe
- Qty. = 1 Jones and Lamson Epic 14 optical comparator
- Qty. = 1 Zeiss 48 x 72 granite surface plate
- Qty. = 1 Starrett 36 x 42 pink granite surface plate
- Qty. = 3 18 x 24 black granite surface plates at machining stations
- Qty. = 1 Granier and Associates 600 Amp Magnetic Partical inspection machine
- Qty. = 1 Brown and Sharpe TESA Height gage
- Qty. = 1 Pratt and Whitney Supermicrometer
- Various gage blocks, gage pins, and thread rings to support operations
- Micrometers, calipers, hard gauges, and test jigs as required by job
- Qty. = 1 Cadillac #45 roll making machine
- Qty. = 1 GT Schmidt roll marking machine
- Qty. = 1 Matthews Pnuematic roll marking machine
- Qty. = 1 Federal # 5 60 Ton OBI press
- Qty. = 1 Bliss 10 ton OBI press
- Qty. = 1 Bliss #21 75 ton OBI press on coil feed line
- Qty. = 1 Verson 25 ton x 78 inch press brake
- Qty. = 1 Miller synchrowave 500 TIG welder
- Qty. = 1 Lincoln 400 amp DC stick welder
- Qty. = 1 Lincoln wirematic 255 250 amp MIG welder
- Qty. = 1 Lincoln Ranger 8 250 amp ac/dc 8kw generator welder, gasoline powered
- Qty. = 2 Oxyfuel welding/ cutting outfits
- Qty. = 1 Hypertherm 45 amp plasma cutter
- Qty. = 1 sweco 42 inch bowl vibratory finisher
- Qty. = 1 Grob 20" throat vertical bandsaw
- Qty. = 1 Doall 36" throat vertical bandsaw
- Qty. = 1 Hyd-Mech H-12 programmable automatic horizontal bandsaw
- Qty. = 1 Pratt Whitney 2A Jig Bore
- Qty. = 1 Ingersoll Rand SSR-EP-60 60 HP rotary air compressor
- Qty. = 1 Ingersoll Rand SSR-EP-25-SE 25 HP rotary air compressor
- Qty. = 1 K.H. Huppert single chamber heat treat furnace, 12 x 12 x 20
- Qty. = 1 K.H. Huppert single chamber hardening furnace 8 x 8 x 16
- Qty. = 1 Thread milling machine
- Qty. = 1 Zeks air dryer
- Qty. = 1 Excello Center lap
- Qty. = 1 Saylor Beall 7.5 HP reciprocating air compressor
- Qty. = 1 5000 lb Daewoo Forklift
- Qty. = 1 Toyota 2700 lb forklift
- Qty. = 1 Case 1845C utility loader with forks and bucket
- Qty. = 1 Ford F350 Crew cab DRW 7.3L Diesel 8 ft. flatbed shop truck
- Qty. = 1 Gatormade 30 foot gooseneck tandem dual Deckover trailer, 22,500 LB GVWR
- 900 square foot assembly/ assembly warehouse area
